Bring the power of Hydrawise® to residential, commercial, and public-sector projects with this affordable powerhouse.

Key Benefits

• Number of stations: Conventional: 8 to 38 (plastic), 8 to 54 (metal and pedestal)* With two-wire EZDS: up to 54 (all enclosure options)
• Standard programming option allows for 6 independent irrigation programs and 6 start times per program
• Advanced programming option provides station based programming with up to 6 total start times available
• Any 2 programs or stations can operate simultaneously, providing more efficient watering 2 sensor inputs available for use with any Clik sensors and HC Flow Meter
• 1 P/MV output for pump start relay and master valve activation Wi-Fi enabled for quick connection to Hydrawise software
• 3 1/4" full-colour touchscreen display for simple programming at the control panel
• Built-in milliamp sensor for wire fault detection and alerts

Operating Specifications

• Transformer input: 120/230 VAC
• Transformer output (24 VAC): 1.4 A
• Station output (24 VAC): 0.56 A
• P/MV output (24 VAC): 0.56 A
• 2.4 GHz (only) Wi-Fi router compatible, 802.11 b/g/n 20 MHz Supported security protocols: WPA/WPA2 Personal (only), TLS
• Approvals: Plastic Wall Mount IP55 (outdoor), Plastic Pedestal IP24, Metal Wall Mount IP55, Metal Pedestal IP55 (outdoor), UL, cUL, FCC, CE, UKCA, RCM
• Warranty period: 2 years

User Installed Options

• Mini-Clik for rain sensor shutdown
• Compatible with both EZ Decoders and the Wireless Valve Link system
• HC Flow Meters to measure water flow
